chamber type resistance furnace

type:resistance furnace

input size:custom made

processed materials:custom made

applications:refractory materials heat treatment lower than 1700 degree

  • overview
  • specifications
  • features

 chamber type atmosphere furnace

application:

suitable for  ceramic, metallurgy, electronic, glass, chemical industry, machinery, fire resistance material, new material development, special kinds of material, constructions materials.

[s]qq图片20171107163351







temperature project

1200℃

1400℃

1600℃

1700℃

1800℃

power ac

220v/380v

220v/380v

220v/380v

220v/380v

220v/380v

max .temperature

1250℃

1450℃

1650℃

1730℃

182o℃

working temperature

1200℃

1400℃

1600℃

1700℃

180o℃

temperature control accuracy

±1℃

±1℃

±1℃

±1℃

±1℃

temperature uniformity in the furnace

±1℃(depends on the chamber size), can adopt multipoint temperature controlling type as per user’s request

±1℃(depends on the chamber size), can adopt multipoint temperature controlling type as per user’s request

±1℃(depends on the chamber size), can adopt multipoint temperature controlling type as per user’s request

±1℃(depends on the chamber size), can adopt multipoint temperature controlling type as per user’s request

±1℃(depends on the chamber size), can adopt multipoint temperature controlling type as per user’s request

temperature measuring element and range

pt-rh s

0-1700℃

pt-rh s

0-1700℃

pt-rh-pt b

0-1820℃

pt-rh-pt b

0-1820℃

pt-rh-pt or optics infrared measuring

programming curve segments

16,32,40 optional

16,32,40 optional

16,32,40 optional

16,32,40 optional

16,32,40 optional

heating speed

1℃/h to 40℃/min adjustable

1℃/h to 40℃/min adjustable

1℃/h to 40℃/min adjustable

1℃/h to 40℃/min adjustable

1℃/h to 40℃/min adjustable

heating element

silicon carbide rod

 feature:

1. temperature uniformity: ±1℃(it depends on the chamber size)
2. operation: programmable,  pid self-adjusting, heat  up automatically, keep temperature automatically, cooling automatically, no need to watch over;  it could connect the computer to control the furnace(start the furnace, stop the furnace,  pause for rising the temperature,  set the heating curve, store the heating curve and history curve)

3. quickly heating (heating speed: 1℃/h to 40℃/min  can be adjusted.)
4.energy saving(the furnace hearth is made of imported fiber with high temperature and hot or cold suddenly resistance)
5. the furnace body is sprayed with excellent corrosion resistance and acid alkali resistance, and the furnace body is separated from the furnace hearth and adopting the air cooling type to get close to the room temperature.
6.double circuit protection(over temperature, over voltage, over current, power failure)
7. the furnace hearth material is imported fire resistance material with excellent temperature keeping, high temperature resistance and suddenly hot or cold resistance.
8.the working temperature:1000 ℃ 1200℃  1400℃  1600℃  1700℃ 1800℃

the standard export packing:
